Description

Product description
Indexing plungers are used where any change in locking position due to lateral forces should be prevented. A new indexed position can be only be moved to after the pin has been manually retracted. Form C and D are recommended for applications where the indexing pin should remain disengaged for an extended period and be prevented from springing back.
These indexing plungers are particularly suitable for mounting on thin-walled components.
Material

Stahlausführung:

Gewindehülse und Arretierstift Automatenstahl.



Edelstahlausführung:

Gewindehülse und Arretierstift 1.4305.



Pilzgriff Thermoplast.

Version
Steel version:
Indexing pin hardened, ground, black oxidised.

Stainless steel version:
Indexing pin not hardened, ground, bright.
Note
These indexing plungers have been specially designed for assembly in thin-walled parts.
Indexing plungers are used where any change in locking position due to lateral forces should be prevented. A new locking position can be set only after the pin has been manually disengaged.
Form C is recommended for applications where the locking pin should remain disengaged for an extended period and be prevented from springing back.
On request
Special versions.
Drawing reference
Form A: non-lockout type
Form C: lockout type
Accessory
A double-ended ring spanner can be supplied as an accessory to tighten the nut.
